Getting Started with Shuffle

Welcome to the Shuffle documentation! This guide will help you get up and running with Shuffle quickly and effectively.

Overview

Shuffle is an open-source automation platform designed specifically for the security industry. You can start using it for free with the following options:

• Open Source (On-Premises)
  Download and install Shuffle in your infrastructure.

• Cloud Signup (SaaS)
  Sign up for Shuffle's cloud-based service and get started quickly. Multi-Tenant data-residency in a near you.

• Hybrid Cloud
  Local automation runner (Orborus) connected to your Shuffle Cloud or Self-hosted setup.

Need help? Check out these resources:

• Training
  Access training resources to get up to speed with Shuffle.
• Old Training Videos
  In case you would like to watch older on-demand training videos. The platform however has significantly improved since then and the current training would be a better match.

Workflow Development

Workflows run the automated processes in Shuffle by connecting Triggers and Actions/APIs.

If you want some practice, check out our default intro to Workflow development

Finding Usecases

Usecases are auto-generated workflows that perform a task together. This can be things like handling EDR alerts, doing phishing analysis or using detection rules with Sigma with your SIEM.

Finding Workflows

Workflows connect Apps together to perform an action, typically getting and setting data with API's and using Shuffle's built in tools like Shuffle Tools to modify or format the data. They can be ran and stopped according to your needs, and typically have one starting point and multiple outputs.

Finding Apps

Apps are API's or Python scripts, and can be modified and built by anyone. To use an existing public app in a Workflow, you must first activate it. Public apps can be forked, meaning you can have your own version of them.

Introduction Blogposts

• 1. Introducing Shuffle - an Open Source SOAR platform
• 2. Getting started with Shuffle
• 3. Creating your first app - Virustotal and TheHive
• 4. On webhooks and loops - TheHive, Cortex and MISP
• 5. Deploying Shuffle :)
• 6. Automation with Shuffle SOAR
• 7. Simplify Your SOAR Implementation with Shuffle

Workflow Principles

1. Variables & nodes
2. JSON autocompletion
3. Loops
4. Nestedloops
5. Start nodes
6. Triggers
7. Subflows
8. App Authentication
9. Loop filtering
10. Shuffle File storage
11. Shuffle Datastore (Cache)
12. Deduplication
13. Liquid formatting
14. HTTP & Rest APIs

Shuffle 101

• Learning Startnodes
• Learning the HTTP app
• Cache Tutorial
• File Tutorial
• App Authentication
• Learning Liquid Formatting
• JSON within Shuffle

Shuffle YouTube Videos

Learn about Shuffle - in-depth
Here's a training session we did on Shuffle.

• 00:00 - 00:30: Introduction to Shuffle and what we're building
• 00:30 - 02:00: Feature walkthrough of tenants, app creator, and workflows
• 02:00 - end: Real-time demo, creating use-cases for attendees

Community Videos

1. Understanding Shuffle

Our friends at have created excellent videos to help you learn about Shuffle. Be sure to check them out!

2. What is SOAR?

Learn the basics of SOAR (Security Orchestration, Automation, and Response) and how Shuffle fits into this ecosystem.
Watch now:

3. Installing Shuffle

Ready to install Shuffle? Follow this step-by-step guide to get Shuffle up and running quickly.
Watch now:

Environment Variables (.env)

The root .env file configures how Shuffle starts, connects services, and executes workflows. Use the table below as a reference for each variable.

Recommended: replace all default passwords and set SHUFFLE_ENCRYPTION_MODIFIER before production use.

Core and bootstrap

Variable	Default	Description
ENVIRONMENT_NAME	Shuffle	Name of the execution environment used by workers.
LIQUID_SANITIZE_INPUT	true	Sanitizes Liquid template input to reduce unsafe input handling.
SHUFFLE_DOWNLOAD_WORKFLOW_LOCATION	``	Remote repository URL/location for downloading workflows on first load.
SHUFFLE_DOWNLOAD_WORKFLOW_USERNAME	``	Username for workflow repository authentication.
SHUFFLE_DOWNLOAD_WORKFLOW_PASSWORD	``	Password/token for workflow repository authentication.
SHUFFLE_DOWNLOAD_WORKFLOW_BRANCH	``	Branch to pull workflows from during bootstrap.
SHUFFLE_APP_DOWNLOAD_LOCATION	https://github.com/shuffle/python-apps	Repository location used to download apps.
SHUFFLE_DOWNLOAD_AUTH_USERNAME	``	Username for app repository authentication.
SHUFFLE_DOWNLOAD_AUTH_PASSWORD	``	Password/token for app repository authentication.
SHUFFLE_DOWNLOAD_AUTH_BRANCH	``	Branch to pull apps from.
SHUFFLE_APP_FORCE_UPDATE	false	Forces app updates even when apps already exist locally.
SHUFFLE_DEFAULT_USERNAME	``	Default admin username created on first startup (min length 3).
SHUFFLE_DEFAULT_PASSWORD	``	Default admin password created on first startup (min length 3).
SHUFFLE_DEFAULT_APIKEY	``	Optional default API key for initial user bootstrap.

Local paths and encryption

Variable	Default	Description
SHUFFLE_APP_HOTLOAD_FOLDER	./shuffle-apps	Local app folder used for hotloading apps.
SHUFFLE_APP_HOTLOAD_LOCATION	./shuffle-apps	Local app location used by Shuffle for loading/saving apps.
SHUFFLE_FILE_LOCATION	./shuffle-files	Base path for Shuffle file storage.
SHUFFLE_ENCRYPTION_MODIFIER	``	Required secret used in authentication encryption. Changing/loss requires reauth for apps.

Backend/frontend and network

Variable	Default	Description
BASE_URL	http://shuffle-backend:5001	Internal backend base URL used by services.
SSO_REDIRECT_URL	http://localhost:3001	Redirect URL used in SSO flows.
BACKEND_HOSTNAME	shuffle-backend	Backend hostname for service communication.
BACKEND_PORT	5001	Backend service port.
FRONTEND_PORT	3001	Frontend HTTP port.
FRONTEND_PORT_HTTPS	3443	Frontend HTTPS port.
AUTH_FOR_ORBORUS	``	Optional auth value used by Orborus when talking to backend.
OUTER_HOSTNAME	shuffle-backend	Public/outer hostname used for local execution callbacks and service routing.
DB_LOCATION	./shuffle-database	Local database/emulator storage location.
DOCKER_API_VERSION	1.40	Docker API version used by Shuffle components.

Proxy, timezone, and runtime mode

Variable	Default	Description
HTTP_PROXY	``	Outbound HTTP proxy for Orborus/worker/app traffic.
HTTPS_PROXY	``	Outbound HTTPS proxy for Orborus/worker/app traffic.
SHUFFLE_PASS_WORKER_PROXY	TRUE	Passes proxy environment variables into workers.
SHUFFLE_PASS_APP_PROXY	TRUE	Passes proxy environment variables into app containers.
SHUFFLE_INTERNAL_HTTP_PROXY	noproxy	Internal HTTP proxy override for Shuffle internal communication.
SHUFFLE_INTERNAL_HTTPS_PROXY	noproxy	Internal HTTPS proxy override for Shuffle internal communication.
TZ	Europe/Amsterdam	Timezone used by Orborus, workers, and apps.
ORBORUS_CONTAINER_NAME	``	Explicit Orborus container name (used for container detection, including cgroup v2 cases).
SHUFFLE_ORBORUS_STARTUP_DELAY	``	Startup delay before Orborus begins processing.
SHUFFLE_SKIPSSL_VERIFY	true	Disables SSL verification for configured Shuffle calls.
IS_KUBERNETES	false	Enables Kubernetes runtime mode when set to true.

Image and deployment behavior

Variable	Default	Description
SHUFFLE_BASE_IMAGE_REPOSITORY	frikky	Docker image repository namespace used for base images.
SHUFFLE_USE_GCHR_OVERRIDE_FOR_AUTODEPLOY	true	Uses GHCR override behavior for autodeploy to avoid re-updating core apps (HTTP, subflow, tools).

Optional variables (commented by default in .env):

Variable	Default	Description
SHUFFLE_BASE_IMAGE_NAME	shuffle	Base image name override.
SHUFFLE_BASE_IMAGE_REGISTRY	ghcr.io	Base image registry override.
SHUFFLE_BASE_IMAGE_TAG_SUFFIX	"-1.4.0"	Optional suffix appended to base image tag.

Orborus execution and scaling

Variable	Default	Description
SHUFFLE_SWARM_BRIDGE_DEFAULT_INTERFACE	eth0	Interface used to resolve container IP in Docker/swarm networking.
SHUFFLE_SWARM_BRIDGE_DEFAULT_MTU	1500	MTU used for bridge networking assumptions.
SHUFFLE_MEMCACHED	``	Optional memcached endpoint/configuration for caching.
SHUFFLE_CONTAINER_AUTO_CLEANUP	true	Automatically removes execution containers after runs.
SHUFFLE_ORBORUS_EXECUTION_CONCURRENCY	5	Soft limit for concurrent executions handled by Orborus.
SHUFFLE_HEALTHCHECK_DISABLED	false	Disables healthcheck endpoints/processes when true.
SHUFFLE_ELASTIC	true	Enables elastic/OpenSearch-related logging/index behavior.
SHUFFLE_LOGS_DISABLED	true	Disables log collection/storage when true.
SHUFFLE_CHAT_DISABLED	false	Disables chat features when true.
SHUFFLE_DISABLE_RERUN_AND_ABORT	false	Disables rerun and abort controls for executions when true.
SHUFFLE_RERUN_SCHEDULE	300	Interval/schedule used for rerun handling.
SHUFFLE_WORKER_SERVER_URL	``	Explicit backend URL for workers if autodetection points to wrong server.
SHUFFLE_ORBORUS_PULL_TIME	``	Poll/pull interval for Orborus execution queue handling.
SHUFFLE_MAX_EXECUTION_DEPTH	``	Maximum recursion depth for subflow execution.
SHUFFLE_APP_REPLICAS	3	Number of app replicas to run.

Datastore and search

Variable	Default	Description
DATASTORE_EMULATOR_HOST	shuffle-database:8000	Datastore emulator host used by Shuffle backend.
SHUFFLE_OPENSEARCH_URL	https://shuffle-opensearch:9200	OpenSearch endpoint URL.
SHUFFLE_OPENSEARCH_CERTIFICATE_FILE	``	Path to custom OpenSearch certificate file.
SHUFFLE_OPENSEARCH_APIKEY	``	API key for OpenSearch authentication.
SHUFFLE_OPENSEARCH_CLOUDID	``	OpenSearch Cloud ID for managed deployments.
SHUFFLE_OPENSEARCH_PROXY	``	Proxy value used for OpenSearch traffic.
SHUFFLE_OPENSEARCH_INDEX_PREFIX	``	Prefix added to generated OpenSearch index names.
SHUFFLE_OPENSEARCH_SKIPSSL_VERIFY	true	Skips SSL verification for OpenSearch connections.
SHUFFLE_OPENSEARCH_USERNAME	"admin"	Username for OpenSearch auth.
SHUFFLE_OPENSEARCH_PASSWORD	"StrongShufflePassword321!"	OpenSearch password used by Shuffle backend and first-time setup.
OPENSEARCH_INITIAL_ADMIN_PASSWORD	"StrongShufflePassword321!"	Initial OpenSearch admin password used during first-time OpenSearch setup.

Other runtime settings

Variable	Default	Description
SHUFFLE_TENZIR_URL	``	Endpoint for Tenzir integration.
SHUFFLE_PROTECTED_CLEANUP_DISABLED	true	Disables protected cleanup safeguards when true.
DEBUG_MODE	false	Enables debug mode and verbose behavior when true.
